BRIDGE RECTIFIERS



OUTLINE DRAWINGS (MEASUREMENTS)



2.0 AMPERE/RS-2

Type

Maximum Peak Reverse Voltage

Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25C TA Maximum Forward Voltage @ 25C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
RS203 200 50 10 2.0 1.1 $ 0.99

RS204 400 50 10 2.0 1.1 $ 1.00

RS205 600 50 10 2.0 1.1 $ 1.29

RS206 800 50 10 2.0 1.1 $ 1.39

RS207 1000 50 10 2.0 1.1 $ 1.49



4.0 AMPERE/KBU

Type

Maximum Peak Reverse Voltage

Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25C TA Maximum Forward Voltage @ 25C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBU401 100 150 10 4.0 1.0 $ 1.19

KBU402 200 150 10 4.0 1.0 $ 1.29

KBU404 400 150 10 4.0 1.0 $ 1.39

KBU406 600 150 10 4.0 1.0 $1.49

KBU408 800 150 10 4.0 1.0 $1.69

KBU410 1000 150 10 4.0 1.0 $1.99



6.0 AMPERE/KBU

Type

Maximum Peak Reverse Voltage

Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25C TA Maximum Forward Voltage @ 25C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBU6005 50 175 10 3.0 1.0 $1.49

KBU601 100 175 10 3.0 1.0 $1.49

KBU602 200 175 10 3.0 1.0 $1.59

KBU604 400 175 10 3.0 1.0 $1.69

KBU606 600 175 10 3.0 1.0 $1.99

KBU608 800 175 10 3.0 1.0 $2.49

KBU610 1000 175 10 3.0 1.0 $2.69



8.0 AMPERE/KBU

Type

Maximum Peak Reverse Voltage

Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25C TA Maximum Forward Voltage @ 25C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
KBU8005 50 200 10 4.0 1.0 $1.99

KBU801 100 200 10 4.0 1.0 $2.09

KBU802 200 200 10 4.0 1.0 $2.19

KBU804 400 200 10 4.0 1.0 $2.29

KBU806 600 200 10 4.0 1.0 $2.39

KBU808 800 200 10 4.0 1.0 $2.69

KBU810 1000 200 10 4.0 1.0 $2.99




35.0 AMPERE/GBPC

Type

Maximum Peak Reverse Voltage

Maximum Forward Peak Surge Current @ 8.3mS Superimposed Maximum Reverse Current @ PVR @25C TA Maximum Forward Voltage @ 25C TA Price Paypal
PRV IFM (Surge) IR IFM VFM
VPK APK μAdc APK VPK
GBPC3504 400 400 10 17.5 1.0 $ 5.90

GBPC3508 800 400 10 17.5 1.0 $ 6.50

GBPC3510 1000 400 10 17.5 1.0 $6.90
